HK-3498A Automatic High Temperature Dropping Point Tester

Overview

　　HK-3498A Automatic High Temperature Dropping Point Apparatus conforms to the ASTM D2265 Standard Test Method for Dropping Point of Lubricating Grease Over Wide Temperature Range.This apparatus covers the determination of the dropping point of lubricating grease and it tests dropping points of lubricating greases at temperatures of up to 400℃

Features

1. Adopt detectable PT100 glass sensor

2. Judge, calculate, print automatically

3. Touch screen operation, storage, upload data

4. Do 4 sets of tests at the same time

Technical parameters

1. Power source:AC 220V±10% 50Hz

2. Power:1500W

3. Detecting mode:Infrared scanning

4. Screen： LCD

5. Alarm mode:Audible and visual alarm system

6. Test holes: 4 holes

7. Ambient requirements:temperature 5~40℃;humidity≤85%
